Ebike light LED 6V Electric Bike Headlight Taillight front light for Bafang BBS02B bbs01b tsdz2b tsdz2 BBSHD Mid drive Motor STARUNION WUXING QD197 QD

Price:
    Please select the information you wantX
  • Model:
    WD216
    WD220
    QD197
    QD197 with bracket
    QD236
    QD236 with bracket
  • Ships From:
    China
    Germany Orange Connex warehouse
Quantity:
-
+
(7010 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from

If you from United Kingdom,Please buy from China or Germany or UK stock,Because OrangeConnex dot com can not delivery the goods from Germany Orange Connex warehouse to Kingdom

Ebike light LED 6V Electric Bike Headlight Taillight front light for Bafang BBS02B bbs01b tsdz2b tsdz2 BBSHD Mid drive Motor STARUNION WUXING QD197 QD236 WD220 WD216

Note:Black(GND)    Black white or Red(+6)

QD197
 It is a front light which pass the K-MARK certification, TPL certification, E-mark and meet many European road traffic standards. Light distribute by a reflect cup, use a 1W high-power LED light source. There are two versions dynamo and E-bike versions. The mounting bracket passes the 72-hours salted spray test,Delicate appearance texture, good weather resistance, while the fixed way is simple, reliable installation, solid. Angle adjustable, can match many vehicle models with different frame geometry.

1.Application

E-bike、E-Scooter、Folding E-bike and other two or three-wheeled Scooter

2.Applicable environment

  Temperature:-20℃~60℃;Humidity:20%~80%

3.Technical Parameters

Waterproof and dustproof level:IP45

Emark EIA,Kmark, TPL

  Power supply form:6V/12V/24V/36V/48V 1.8W DC power supply mode

Wire definition:

DC power supply modeàthe power connects to the positive/negative.

4.Numbering rules of light series

The product number of Front Light:QD197

Meaning:197-Model  QD-product category,Front light

5.The chart of product dimensions:

QD236

Using high-power LED light source, the maximum illuminance of the light spot at a distance of ten meters reaches 30 Lux. Dedicated driver chip for more stable and pleasant sound quality. Choice of stainless steel or electrophoretic black bracket.


Size L 66mm  W 52mm  H 71mm (Without bracket)
Weight 85g
Material PC+ABS
Output connector type Standard 0.5 x 2.8mm pins or custom
Waterproof IPX4
Horn 85±5dB
Power 2.4W
Voltage DC 12-60V
Center Luminance 30LUX
Light Source LED



WD220
Approval CE / GB/T 31887.1-2019
Size  L 95mm W 45mm H 19mm
Weight     46g
Waterproof     IPX4
Material  PMMA+ABS
Assemble Dimension      50mm
Voltage   DC 6V
Power      0.6W
Light Source    LED
Three sets of high-power LEDs provide light sources and are equipped with precision light guide strips; Fully sealed waterproof design, more secure and reliable.

WD216
Approval CE/StVZO/ECE/GB/T 31887.1-2019
Size  L 90mm  W 40mm  H 16mm
Weight     46g
Waterproof     IPX4
Material  PMMA+ABS
Assemble Dimension      50mm
Voltage    DC6V
Power      0.5W
Light Source    LED
High power LED provides light source, equipped with precision light guide strip; Fully sealed waterproof design, more secure and reliable.




Packing list:

1pcs  Rear DC 6V WD216 or WD220 or QD197 or QD236 STARUNION WUXING light
