BAFANG BBS02B 48V 750W M315 CAN Bus Mid Drive Motor Electric Bicycle eBike Conversion Kit MM G340.750.C

BF-48X750
Price:
USD
$319.00
    Please select the information you wantX
  • LCD:
    SW102
    860C
    DP C010
    DZ41
    B02N-C
    No display
  • Chainwheel:
    44T
    46T
    48T
    52T
    None
  • Brake Type:
    Brake lever
    Hydraulic Brake Sensor
    None
  • Free Gift:
    None
    Include Free Gift
  • Ships From:
    Germany
    USA
Quantity:
-
+
(119980 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from

free shippingprice include delivery fee
From Pswpower

48V 750W Bafang Mid Drive Motor

Feature:

Power Cable:
XT60 Male,Battery need XT60 Female connector.
Battery Communication Cable:
you can ignore the communication cable if you do not use bafang battery.
Front Light Cable:
DC output 52V-36V Current 0.07A. Red positive pole, Black negative pole.
Rear Light Cable:
DC output 10.4V-7.2V Current 0.014A. White positive pole, Black negative pole.




Specification:

Core Data
Position: Mid Motor
Construction: Geared Motor
Nominal Voltage: 48V
Rated Power: 750w
RPM: 130-150
Max Torque: 160 N.m
Efficiency: 85%
PAS SENSOR: Speed sensor
Shaft Standard: JIS
Mounting Parameters
Weight: 4.8 kg
Function
E-Brake:Yes
Gearsensor Function:Yes
Light Drive Capacity(DCV/W):6/3(max)
Further Specifications
Cadence (Pulses/Cycle):N/A
Reduction Ratio: 1:21.9
Magnet Poles:8
Noise: <55dB
Hall Sensor: optional
Connector: Waterproor
Tests & Certifications
IP-Code:IP 65
Cerifications: CE /UL / ROHS EN 14764

How to choose 48V or 52V Motor?

This New version CAN Bus have 48V motor and 52V motor. 48V motor is compatible with 48V ( max output voltage 54.6V) batteries. 52V motor is compatible with 52V ( max output voltage 58.4V) and 48V( max output voltage 54.6V)  batteries, please choose right version base on your battery voltage.

If you use 48V (max output voltage 54.6V ) battery for 52V motor.LCD will display wrong battery capacity.Battery can not Completely discharged。 But motor work normal.

If you use 52V (max output voltage 58.8V ) battery for 48V motor.LCD will display ERROR 07( it is means over voltage).  motor can not work



How to choose the brake lever or hydraulic brake sensor?

The kit will work with or without the brake sensors plugged in.

The Bafang kit does not come with brake sensors, you can select the brake levers option made for standard cable actuated brakes.

You also have the option of getting magnet sensors which allows you to adapt your existing brakes.  This will help with users who have hydraulic brakes the sensors are not compatible with.
